NTC元件

技术注释

NTC元件 选型指南

传感器头直径 加工 B常数容差 / mm 电阻公差 温度范围
d≤1 1<d≤2 2<d≤3 接合 铆接 烧结 焊接 熔接 ±0.3% ±1% ±2% ±1% ±2% ±3% ±5%
无引线 L860 / S860
(B57860L*)
(B57860S*)
传感器,NTC元件:L860
● ● ● ● ● ● ● -40 ～ 175℃
玻璃封装型 G1560
(B57560G1*)
● ● ● ● ● ● ● -40 ～ 300℃
G1550
(B57550G1*)
● ● ● ● ● ● -40 ～ 300℃
G1540
(B57540G1*)
● ● ● ● ● ● -40 ～ 250℃
G1561
(B57560G1*)
● ● ● ● ● ● ● -40 ～ 260℃
G1551
(B57550G1*)
● ● ● ● ● ● -40 ～ 260℃
G1541
(B57541G1*)
● ● ● ● ● ● -40 ～ 250℃
NTCDSxxxx3
● ● ●* ● ● ● ● -40 ～ 250℃
NTCDSxxxx4 ● ● ●* ● ● ● ● -40 ～ 250℃
NTCDAxxxx3
● ● ●* ● ● ● ● -40 ～ 250℃
NTCDAxxxx4 ● ● ●* ● ● ● ● -40 ～ 250℃
NTCDExxxx3
● ● ●* ● ● ● ● -40 ～ 250℃
NTCDExxxx4 ● ● ●* ● ● ● ● -40 ～ 250℃
NTCDZxxxx3
● ● ●* ● ● ● ● -40 ～ 160℃
NTCDZxxxx4 ● ● ●* ● ● ● ● -40 ～ 160℃
树脂涂层型 S861
(B57861S*)
● ● ● ● ● ● ● ● ● -40 ～ 155℃
L862
Under
Development
● ● ● ● ● ● ● ● ● -40 ～ 155℃
S864
(B57864S*)
● ● ● ● ● ● ● ● -40 ～ 155℃
S871
(B57871S*)
● ● ● ● ● ● ● ● -40 ～ 155℃

(*) 焊接需要镀锡处理的选购件。最高温度：160℃
