薄膜太阳电池

积层贴片陶瓷片式电容器

C5750C0G2A154J230KE

Capacitance=150nF
Edc=100V
T.C.=C0G

LxWxT:5.7x5x2.3mm
Soft termination

积层贴片陶瓷片式电容器

CGA3E3X8R2A223K080AD

Capacitance=22nF
Edc=100V
T.C.=X8R

LxWxT:1.6x0.8x0.8mm
Conductive Epoxy
AEC-Q200

积层贴片陶瓷片式电容器

CGA8M1X7R3A103M200KA

Capacitance=10nF
Edc=1000V
T.C.=X7R

LxWxT:4.5x3.2x2mm
High Volt. (1000V and over)
AEC-Q200

积层贴片陶瓷片式电容器

CGA9P3X7R1H226M250KB

Capacitance=22μF
Edc=50V
T.C.=X7R

LxWxT:5.7x5x2.5mm
General
AEC-Q200

直流链路用电容器

B32716H8685K000

6.8uF, 800 V DC

24.0mm(W) x 15.0mm(H) x 42.0mm(L)

SMD/SMT 电感器(线圈)

MHQ1005P5N6STD25

L=5.6nH
Q=23

L x W x T :
1 x 0.6 x 0.5mm

SMD/SMT 电感器(线圈)

MLF1608A3R3JT000

L=3.3μH
Rated current=30mA

L x W x T :
1.6 x 0.8 x 0.8mm

SMD/SMT 电感器(线圈)

SPM5012T-2R2M-LR

L=2.2μH
Rated current=3.2A

L x W x T :
5.4 x 5.1 x 1.2mm

贴片压敏电阻/陶瓷瞬时电压抑制器

B72580E0350K062

Maximum continuous voltage=45V

Maximum Clamping Voltage (8/20μs)=90V

引线式盘压敏变阻器

B72214X2421K501

Max. Operating Voltage [AC]=420Vrms

Max. Surge Current Imax(8/20μs,1time)=5000A
