铁氧体附件

嵌入式, 多引脚, 大尺寸电容器

B43642A2108M060

1000µF/200V DC

22mm dia x 50mm length

SMD/SMT 电感器(线圈)

B82432T1474K000

L=470μH
Rated current=0.161A

4.5mm x 3.2mm [EIA 1812]

SMD/SMT 电感器(线圈)

B82477P4683M000

L=68μH
Rated current=2.45A

12.5mm x 12.5mm

SMD/SMT 电感器(线圈)

VLS5045EX-2R2N

L=2.2μH
Rated current=6.4A

L x W x T :
5 x 5 x 4.5mm

贴片压敏电阻/陶瓷瞬时电压抑制器

B72500T8250L060 (High speed)

Maximum continuous voltage=32V

Maximum Clamping Voltage (8/20μs)=120V

贴片压敏电阻/陶瓷瞬时电压抑制器

B72542V6300K062

Maximum continuous voltage=38V

Maximum Clamping Voltage (8/20μs)=77V

浪涌电流限制器NTC

B57235S0509M051

Resistance (at 25℃)=5Ω

Maximum Current=4.2A

浪涌电流限制器NTC

B57236S0229M000

Resistance (at 25℃)=2.2Ω

Maximum Current=6A

过电流保护PTC

B59890C0120A070

Max. operating voltage=265V

Rated resistance=150Ω

电流互感器

B82801B0205A100

Sensed Current=20A max

TR=1:100
